Liquid crystal display

For status monitoring and set-up

Day/night timing of the load output

This option allows for a pre-set ON-time after dusk.

Programmable battery charge algorithm

Preprogrammed algorithms for AGM, GEL, Flooded or LiFePO4 batteries (with internal BMS only)

Two 5 Volt USB outputs

Maximum current (both outputs combined): 2A

Brand	Victron Energy
Manufacturer Part Number	SCC010030050
GTIN	8719076046226
Battery Voltage	12/24 V automatic system voltage detection
Rated Charge Current	30A
Maximum Solar Voltage	28V / 55V
Load Output	Manual control + low voltage disconnect + timer
Grounding	Common positive
IP Rating	IP20
Dimensions	H101 x W184 x D47mm
Weight	0.3Kg
Warranty	5 Years
